Wattage:
Voltage:
EAN:
Manufacturer:
Constant CurrentFully isolated plastic caseProtections: Short circuit/ Overload/ Over voltageOther features: Universal AC input / Full RangeSmall and compact sizeWithstand 300VAC surge input for 5 secondsIsolation class II, no FGCooling by free air convectionPass LPS100% full load burn-in testLow cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 25 Output Current Choose Option Dimmable (Type) No Dimensions 84x 57x 29.5 (LxWxH) mm EMC Standards EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A Input Voltage 90~264VAC, 127VDC~370VDC Safety Standards Design refer to EN60950-1, UL8750 Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APC-25-spec_2.pdf
More Information Manufacturer Mean Well Output Wattage (W) 25 Output Current Choose Option Dimmable (Type) No Dimensions 84x 57x 29.5 (LxWxH) mm EMC Standards EN55022, EN61000-3-2 Class A, EN610003-3, EN55024, EN61000-4-2, 3, 4, 5, 6, 8, 11; light industry level (surge 2KV), criteria A Input Voltage 90~264VAC, 127VDC~370VDC Safety Standards Design refer to EN60950-1, UL8750 Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APC-25-spec_2.pdf
