Wattage:
Voltage:
EAN:
Manufacturer:
Constant Voltage
Fully isolated plastic case
Protections: Short circuit/ Overload/ Over voltage
Other features:
Universal AC input / Full Range
Small and compact size
Isolation class II, no FG
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 15 Output Voltage 15V Dimmable (Type) No DC Output Adjustment N/A Dimensions 77 x 40 x 29 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 Input Voltage 90~264VAC; 127~370VDC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APV-16-5_20spec_1_.pdf
More Information Manufacturer Mean Well Output Wattage (W) 15 Output Voltage 15V Dimmable (Type) No DC Output Adjustment N/A Dimensions 77 x 40 x 29 EMC Standards EN55015, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547 Input Voltage 90~264VAC; 127~370VDC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13, UL8750 Output Voltage Options Single Working Temperature -30°C~+70°C (Refer to "Derating Curve") PDF Datasheet APV-16-5_20spec_1_.pdf
