Description
Built-in active PFC function, PF>0.9 for 75% of load or higherIP66 designProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 295VAC) / Full rangeMeet 4kV surge immunity level (IEC61000-4-5)Class 2 power unitCooling by free air convectionSuitable for dry,damp and wet locationSuitable for LED lighting and moving sign applications3 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
100
Output Voltage
24V
Dimmable (Type)
No
DC Output Adjustment
+/-10% rated output voltage
Dimensions
193 x 62.5 x 40.5
Input Voltage
90~295VAC, 127~417VDC
Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13
Output Voltage Options
Single
Working Temperature
-30~+70°C (refer to output derating curve)
PDF Datasheet
CEN-100-SPEC.PDF
