Wattage:
Voltage:
EAN:
Manufacturer:
Built-in active PFC function, PF>0.9 for 75% of load or higherIP66 designProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 295VAC) / Full rangeMeet 4kV surge immunity level (IEC61000-4-5)Class 2 power unitCooling by free air convectionSuitable for dry,damp and wet locationSuitable for LED lighting and moving sign applications3 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) No DC Output Adjustment +/-10% rated output voltage Dimensions 183 x 62.5 x 40.5 EMC Standards EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~295VAC, 127~417VDC Safety Standards UL8750, UL879, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single Working Temperature -30~+70°C (refer to output derating curve) PDF Datasheet CEN-75-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 75 Output Voltage 24V Dimmable (Type) No DC Output Adjustment +/-10% rated output voltage Dimensions 183 x 62.5 x 40.5 EMC Standards EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~295VAC, 127~417VDC Safety Standards UL8750, UL879, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single Working Temperature -30~+70°C (refer to output derating curve) PDF Datasheet CEN-75-SPEC.PDF
