Wattage:200
Voltage: 24V
EAN:
Manufacturer: Mean Well
The Mean Well ELG-200-24A-3Y is a 200W 24V LED driver with constant voltage and constant current output in an IP65/IP67 metal housing, for indoor or outdoor installation. The A-type has an output adjustable by potentiometer.
- Constant current plus constant voltage mode output
- Metal housing with functional ground
- Short circuit, over voltage, over temperature and over current protection
- Built-in active PFC, standby consumption under 0.5W
- IP65 / IP67 rated
- Lifetime over 50,000 hours, 5 year warranty
| Wattage | 200W (8.4A rated, 201.6W) |
| Output Voltage | 24V |
| Output Current | 8.4A |
| Voltage Adjustment | Via potentiometer |
| Dimensions | 244 x 71 x 37.5 mm |
| Ingress Protection | IP65 / IP67 |
| Working Temperature | Tcase -40 to +90°C |
