Description
IP65 design for indoor or outdoor installations
Built-in active PFC, PF>0.9 for 60% of load or higher
5 years warranty
Protections: Short circuit / Over current / Over voltage / Over temperature
Other features:
Universal AC input (up to 305VAC) / Full range
High efficiency up to 95%
Output current adjustable through output cable or internal potentiometer
Cooling by free air convection
Suitable for LED lighting and street lighting applications
Meet 4KV surge immunity level (IEC61000-4-5)
Optional CQC models available
Built-in active PFC, PF>0.9 for 60% of load or higher More Information
Manufacturer
Mean Well
Output Wattage (W)
150
Dimmable (Type)
Choose Option
DC Output Adjustment
+/-10% rated output voltage
EMC Standards
EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547
Input Voltage
90~305VAC, 127~431VDC
Safety Standards
UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13, UL1012, UL60950-1
Output Voltage Options
Single
Working Temperature
-40~+70°C (refer to output derating curve)
PDF Datasheet
HLG-150H-spec_8.pdf
