Wattage:
Voltage:
EAN:
Manufacturer:
Constant current designOutput current adjustable through internal potentiometerProtections: Short circuit / Over voltage / Over temperatureUniversal AC input / Full range (up to 305VAC)Built-in active PFC functionCooling by free air convectionIP65 design for indoor or outdoor installationsSuitable for dry / damp / wet locationsHigh efficiency up to 91%5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 70 Output Current 3500mA Dimmable (Type) 1-10VDC, PWM signal, resistance Output Voltage Range (V) 100~200 Dimensions 171x 61.5x 36.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (¡Ù60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A Input Voltage 90~305VAC, 127VDC~431VDC Safety Standards UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent, IP65 approved Output Voltage Options Single Working Temperature -40~+50°C (refer to output derating curve) PDF Datasheet HLG-60H-C-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 70 Output Current 3500mA Dimmable (Type) 1-10VDC, PWM signal, resistance Output Voltage Range (V) 100~200 Dimensions 171x 61.5x 36.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (¡Ù60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge L,N-FG: 4KV), criteria A Input Voltage 90~305VAC, 127VDC~431VDC Safety Standards UL8750, CSA C22.2 No. 250.0-08, EN61347-1, EN61347-2-13 independent, IP65 approved Output Voltage Options Single Working Temperature -40~+50°C (refer to output derating curve) PDF Datasheet HLG-60H-C-spec.pdf
