Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Long lamp life
- No adverse effect from frequent on/off switching
- Automatic restart after lamp replacement
- Perfect lamp start for applications with motion sensors
- VDE/VDE EMC certified system
- Very high energy efficiency due to cut-off technology
Areas of application
- Open-plan offices, corridors and storage rooms
- Public buildings
- Strip lighting
- Suitable for luminaires of protection class I
Technical Data
Electrical data
Input voltage AC
198…264 V
Nominal voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage DC
185…264 V
Maximum output power
70 W
Efficiency in full-load
91 %
Operating frequency
40…50 kHz
Max. ECG no. on circuit breaker 10 A (B)
17
Max. ECG no. on circuit breaker 16 A (B)
28
Inrush current
15 A
Light technical data
Starting time
2.0 s
Dimensions & weight
Length
280.0 mm
Width
30.0 mm
Height
28.0 mm
Mounting hole spacing, length
270.0 mm
Product weight
182.00 g
Cable cross-section, output side
0.5…1.5 mm²
Cable cross-section, input side
0.5…1.5 mm²
Temperatures & operating conditions
Ambient temperature range
-15…+50 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 h
Additional product data
Suitable for lamp power (1 lamp)
58…70 W
Capabilities
End of lamp life safety shutdown
EOL T.2
Suitable for fixtures with prot. class
I
Intended for no-load operation
No
Max. cable length to lamp/LED module
2.0 m / 1.0 m
Dimmable
No
Certificates & standards
Approval marks – approval
VDE / VDE-EMC / ENEC 10 / CE
EEI – Energy Label
A2
Standards
Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547
Type of protection
IP20
Protection class
I
Logistical data
Commodity code
850410809000
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration
14-04-2022
Primary Article Identifier
4008321294227
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
553f952c-32f6-4842-beaa-87800b1b86b1
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
|---|---|---|---|---|
| 4008321294227 | UNV
|
1 | 280mm x 30mm x 28mm | 182.00g |
| 4008321294234 | VS
|
20 | 303mm x 132mm x 185mm | 3853.00g |
