LND154-BL Smart E-Dim DALI DRIVER

http://www.easeic.com/uploadfiles/pdf/201512151111020.pdf

• SMART LND XL Multilevel Constant Current DALI Dimmable 54W
• SMART LND BL 54W 12-42V 1050-1750mA DALI Dimmable 100-240Vac

• Constant Current output 1050-1750mA.
  Multi-power driver supplied with dip-switch for the selection of the output current.
  DALI digital dimming control interface, compatible with standard(IEC62386 ) DALI interfaces.
  Memory function for sets or light groups. Recall of stored functions.
  Dimming range from 0 -100%,LED start at 0.1% possible.
  PUSH-Dim, dimming and switching via push-button with memory function.
  Universal AC power supply,100 - 277VAC 50/60Hz input
  Class II protection against electric shock for direct or indirect contact.
  It can be used for lighting equipment in protection class I and II.
  Supplied with terminal cover and cable retainer.
  Driver can be secured with slot for screws.
  Can be switched on and off on secondary circuit for power LED.
  Protections: Short circuit , Over voltage, Over Current , Over temperature
  5 year warranty
