LPC-100-500 - Mean Well LED Driver LPC-100-500 Series 500mA 100W

Constant current designProtections: Short circuit / Over voltageUniversal AC input / Full rangeWithstand 300VAC surge input for 5 secondsHigh efficiency up to 90%Cooling by free air convectionFully encapsulated with IP67 levelFully isolated plastic caseClass II power unit100% full load burn-in testLow Cost, High reliability2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Current 500mA Dimmable (Type) No Output Voltage Range (V) 100~200 DC Output Adjustment 100-200V Dimensions 190x 52x 37 EMC Standards Compliance to EN55022 (CiSPR22) Class B; EN61000-3-2 Class A(<80% load); EN61000-3-3. Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A. Input Voltage 90-264VAC Safety Standards IP67 approved, Design refer to TUV EN60950-1 Output Voltage Options Single Working Temperature -25°C-+50°C PDF Datasheet LPC-100-spec.pdf
