Description
Built-in active PFC functionProtections: Short circuit/ Over voltage/ Over temperatureOther features:Constant Current mode outputPlastic housing with Class II designIP67 rating for indoor or outdoor installationsClass 2 power unitFunction: 3 in 1 dimmingTypical lifetime>50000 hours5 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
60
Output Voltage
54V
Dimmable (Type)
1-10VDC, PWM signal, resistance
Dimensions
162.5x 43x 32
EMC Standards
Compliance to FCC part 15 class B (@load>60%) Compliance to IEC61000-4-2,4,5; light industry level (surge immunity : Line-Line:2KV)
Input Voltage
200-400VAC, 282-565VDC
Safety Standards
UL8750(type"HL"), CSA C22.2 No. 250.0-08(except for 48V, 54V), IP67 approved
Output Voltage Options
Single
Working Temperature
-40-+90°C
PDF Datasheet
LPFH-60D-SPEC.pdf
