Wattage:
Voltage:
EAN:
Manufacturer:
Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit/ Overload/ Over voltage
Other features:
Universal AC input / Full Range
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Voltage 36V Dimmable (Type) No DC Output Adjustment N/A Dimensions 190 x 52 x 37 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C PDF Datasheet LPV-100-spec_2.pdf
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Voltage 36V Dimmable (Type) No DC Output Adjustment N/A Dimensions 190 x 52 x 37 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C PDF Datasheet LPV-100-spec_2.pdf
