Osram Halotronic HTL 225W /230V

50W-225W 12V transformer

Product family benefits _ Very low power loss thanks to high efficacy _ Through-wiring possible on the primary side _ Large temperature range _ Protective operation throughout the entire partial-load range for long lamp life _ High efficiency Areas of application _ Effect and accent lighting _ Living rooms _ Object lighting _ Conference rooms _ Restaurants _ Recessed and surface-mounted furniture luminaires _ Shop lighting _ Event rooms Product datasheet HTL 225/230…240 HALOTRONIC-PROFESSIONAL HTL | Electronic transformers for low-voltage halogen lamps Product family features _ Line frequency: 50…60 Hz _ RI suppression: to EN 55015 (A1: 2007)/CISPR 15, EN 55022 _ Line harmonics according to EN 61000-3-2 _ Immunity according to EN 61547 _ Safety: to EN 61347 _ Short-circuit protection, overload protection, overtemperature protection: electronically reversible _ Electrical isolation between the primary side and the secondary side _ Energy efficiency: ≥ 91 % (according to ErP regulation 2012/1194/EC) _ Dimmable on the leading edge and trailing edge __ March 30, 2021, 14:03:28 © 2021, OSRAM GmbH. All rights reserved. HTL 225/230…240 Page 1 of 5 Technical data Electrical data Lamp wattage 50…225 W Line current 0.90 A 1) Input voltage DC 176…275 V Nominal voltage 230…240 V Power factor λ 0.95 2) Operating frequency 50 kHz 3) Nominal output voltage 11.6 / 11.7 V 4) Input voltage AC 207…264 V Mains frequency 50…60 Hz System wattage 230.00 W Input voltage range 230…240 V Max. ECG no. on circuit breaker 10 A (B) 11 Max. ECG no. on circuit breaker 16 A (B) 18 Galvanic isolation primary/secondary 4.00 kV 5) ECG efficiency 95 % 6) Inrush current 1.5 A 7) 1) Effectively 2) Minimum 3) Approximately 4) 225 W / 50 W 5) eff 6) At full load 7) Maximum Dimensions & weight Length 170.0 mm Width 44.0 mm Product datasheet __ March 30, 2021, 14:03:28 © 2021, OSRAM GmbH. All rights reserved. HTL 225/230…240 Page 2 of 5 Height 34.0 mm Cable cross-section, input side 2.5 mm² 1) Cable cross-section, output side 4.0 mm² 1) Wire preparation length, input side 14 / 8.0 mm 2) Wire preparation length, output side 14 / 8.0 mm 2) Mounting hole spacing, length 140.0 mm Product weight 225.00 g 1) Maximum 2) Cable sheath / Wire Temperatures & operating conditions Ambient temperature range -20…+50 °C Maximum temperature at tc test point 80 °C Additional product data Design / version Long with cable clamp Capabilities Dimming method Trailing- or leading-edge phase control for inductive load dimmers Overload protection Automatic switch off, reversible Overheating protection Automatic switch off, reversible Short-circuit protection Automatic switch-off, reversible Max. cable length to lamp/LED module 2.0 m Cable/wire types, input side H03VV-F 2x0.50 / H03VV-F 2x0.75 / H03VVH2-F 2x0.75 / H05VVH2-F 2x0.75 / H05VV-F 2x2.5 / NYM-O 2x1.5 / NYM-J 3x1.5 mm² Cable/wire types, output side H03VV-F 2x0.75 / H05VVH2-F 2x0.75 / H05VV-F 2x1.5 / H05VV-F 2x2.5 / NYM-O 2x1.5 / NYM-J 3x1.5 / NYM-J 3x2.5 mm² Dimmable Yes Dimming range 0…100 % No-load proof Yes Suitable for fixtures with prot. class II Certificates & standards Approval marks – approval ENEC 10 / VDE / VDE-EMC / EAC Standards Acc. to EN 61347/Acc. to EN 55015/Acc. to EN 61000- 3-2/Acc. to EN 61547/Acc. to EN 61047 Type of protection IP20 Product datasheet __ March 30, 2021, 14:03:28 © 2021, OSRAM GmbH. All rights reserved. HTL 225/230…240 Page 3 of 5 Logistical data Commodity code 850440909000 Download Data File User instruction HTLHTMHTN UI 080518 Addon Technical Information 321707_ATI HTL 225 (GB) Certificates 334969_ENEC-Marks approval Certificates 504178_EAC HT family Certificates VDE ENEC Certificate 40024665 Certificates HALOTRONIC EMC 134590 080720 Certificates VDE EMC Dertificate 40024187 Declarations of conformity 710835_EC-DOC Halotronic Installation/Operation notice 334738_HALOTRONIC – Manual CAD data 3-dim 317452_HTL 105230-240 and HTL 225230-240 9900052 CAD data 3-dim 317453_HTL 105230-240 and HTL 225230-240 9900052 CAD data 3-dim 317454_HTL 105230-240 and HTL 225230-240 9900052 CAD data PDF 317451_HTL 105230-240 and HTL 225230-240 9900052 Logistical Data Product code Product description Packaging unit (Pieces/Unit) Dimensions (length x width x height) Volume Gross weight 4008321927026 HTL 225/230…240 Shipping carton box 10 182 mm x 89 mm x 230 mm 3.73 dm³ 2361.00 g The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit. Product datasheet __ March 30, 2021, 14:03:28 © 2021, OSRAM GmbH. All rights reserved. HTL 225/230…240 Page 4 of 5 Disclaimer Subject to change without notice. Errors and omission excepted. Always make sure to use the most recent release. Product datasheet __ March 30, 2021, 14:03:28 © 2021, OSRAM GmbH. All rights reserved. HTL 225/230…240 Page 5 of 5
