Product family features
Line frequency: 0 Hz | 50 Hz | 60 Hz
Versatile scope of application thanks to an output power range of up to 300 W
Supply voltage: 220…240 V
Available with output current range: up to 1,000 mA
Constant Lumen Output (CLO)
Integrated customizable thermal management (Driver Guard)
Non-isolated drivers
DALI-2 certified (Part -101,-102, -207, -251, -252, -253)
Product family benefits
Fully programmable via T4T software (NFC, DALI Interface)
Lifetime: up to 100,000 h (temperature at Tc = 75 °C, max. 10 % failure rate)
High light quality: 1…100% amplitude dimming and <1% output ripple current
Wide operating temperature range: -25…+55 °C
High surge protection: up to 4 kV (L-N) / 4 kV (L/N-PE)
Integrated inrush current limiter
Very high efficiency (up to 96%)
Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
Very low standby power consumption: < 0.25 W
Versatile scope of application due to DALI Technology:
Easy to use in corridors and restrooms because of three-level Corridor function
Touch DIM application: easy to control via pushbutton or sensor
Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
Feedback of power consumption and operating hours (Fit for SMART GRID)
Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
Luminaire information for easy maintenance
Advanced luminaire/driver data (power, energy, operating hours…) for analytics
Areas of application
Linear lighting solutions for industry, storage areas and retail applications
Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
Suitable for installation in emergency lighting systems according to EN 60598-2-22
Suitable for luminaires of protection class I
