Description
HID-PV C 70 /S CDM 220-240V 50/60Hz NG - 85974400- Philips - PVC070SCDM
9137006529
Specifications
- General information
-
Type Version ngLamp Type CDMNumber of Lamps 1 piece/unitSuitable For Outdoor Use NoNumber of Products on MCB (16A Type B) (Nom) 20Automatic Restart Yes - Operating and electrical
-
Input Voltage 220 to 240 VInput Frequency 50 to 60 HzOperating Frequency (Nom) 0.14 kHzPower Factor 100% Load (Nom) 0.95Ignition Voltage (Max) 4.0 kVIgnition Switch-Off Time (Nom) 18 minMains Voltage Performance (AC) -10%-+6%Mains Voltage Safety (AC) -18%-+10%Inrush Current Width 0.33 msConstant Wattage Deviation -3%/+3%Power Losses (Nom) 7.0 WInrush Current Peak (Max) 33 AEfficiency at full load [%] 90.60000000000001 % - Wiring
-
Cable Capacity Output Wires Mutual (Nom) 100 pFCable Length From Device to Lamp 1.5 mBallast Contact Wire Cross Section 0.50-2.50 mm²Connector Type Insert - System characteristics
-
Rated Ballast-Lamp Power 70 W
- Temperature
-
T-Ambient (Max) 50 °CT-Ambient (Min) -20 °CT-Storage (Max) 80 °CT-Storage (Min) -25 °CT-Case Lifetime (Nom) 80 °CT-Case Maximum (Max) 80 °C - Mechanical and housing
-
Housing /S
- Approval and application
-
Active Temperature Protection YesEMI 9 kHz ... 300 MHz CISPR 15 ed 7.2Safety Standard EN 61347-2-12Quality Standard ISO 9000:2000Environmental Standard ISO 14001Harmonic Current Emission Standard EN 61000-3-2EMC Immunity Standard EN 61547Vibration Standard IEC68-2-6 F cBumps Standard IEC 68-2-29 EbHumidity Standard IEC 928-13Approval Marks CE marking
ENEC certificate
Hum And Noise Level 37 dB(A) - Product data
-
Full product code 872790085974400Order product name HID-PV C 70 /S CDM 220-240V 50/60Hz NGEAN/UPC - Product 8711500881694Order code 913700652966Numerator - Quantity Per Pack 1Numerator - Packs per outer box 12Material Nr. (12NC) 913700652966Net Weight (Piece) 0.216 kg
