Description
180~295VAC inputBuilt-in active PFC functionProtections: Short circuit/ Over temperatureOther features:Constant current designFully isolated plastic caseIP30 designClass 2 power unit/ Pass LPSIsolation class II, no F.G.100% full burn-in testCooling by free air convection3 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
60
Output Current
1750mA
Dimmable (Type)
No
Dimensions
128x 60x 31.5
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A
Input Voltage
180~295VAC
Safety Standards
UL8750, ENEC EN61347-1, EN61347-2-13 independent, IP30 approved
Output Voltage Options
Single
Working Temperature
-30~+50°C
PDF Datasheet
PLD-60-spec_13.pdf
