Description
Constant current designBuilt-in active PFC functionProtections: Short circuitOther features:Universal input/ Full range (110~295VAC)No load power consumption <0.5WCooling by free air convectionFully isolated plastic caseSmall and compact sizeClass II power unit, no FG100% full load burn-in testHigh reliability, low costSuitable for LED lighting and moving sign applications2 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
25
Output Current
1050mA
Dimmable (Type)
No
Output Voltage Range (V)
9.6~24
Dimensions
145x 38x 22
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547, light industry level (surge 2KV), criteria B
Input Voltage
110~295VAC, 156~417VDC
Safety Standards
Design refer to EN61347-1, EN61347-2-13
Output Voltage Options
Single
Working Temperature
-30~+50°C
PDF Datasheet
PLM-25-spec_3.PDF
