Description
Constant current designThree-step analogue dimmingProtections: Short circuit/ Over temperatureOther features:Universal AC input (up to 295VAC)/ Full rangeBuilt-in active PFC functionNo load power consumption <0.5WCooling by free air convectionIP30 designFully isolated plastic caseClass II power unit, no FG100% full load burn-in testHigh reliability, low costSuitable for indoor LED lighting applications2 years warranty More Information
Manufacturer
Mean Well
Output Wattage (W)
40
Output Current
1750mA
Dimmable (Type)
No
Output Voltage Range (V)
12~23
Dimensions
175x 42x 24
EMC Standards
Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547, light industry level (surge 2KV), criteria B
Input Voltage
90~295VAC 127~417VDC
Safety Standards
UL8750, CSA C22.2 No.250. 13-12 (for PLM-40-1400/ 1750), ENEC EN61347-1, EN61347-2-13, EN61347-2-13, EN62384, IP30 approved
Output Voltage Options
Single
Working Temperature
-30~+60°C
PDF Datasheet
PLM-40-spec_2.pdf
