Wattage:
Voltage:
EAN:
Manufacturer:
Built-in constant current limiting circuit (C.V. + C.C. mode)Fully isolated plastic case with IP64 levelProtections: Short circuit/ Overload/ Over voltage/ Over temperatureOther features: Universal AC input / Full RangeBuilt-in active PFC function, PF>0.9 for 75% of load or higherClass 2 power unit/ Pass LPSIsolation class II, no F.G.User adjustable output voltage and current protection levelCooling by free air convection2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 30 Output Voltage 20V Dimmable (Type) No DC Output Adjustment 95%~108% rated output voltage adjustable by internal potentiometer Dimensions 145 x 47 x 30 EMC Standards EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~295VAC Safety Standards UL8750, UL1310, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet PLN-30-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 30 Output Voltage 20V Dimmable (Type) No DC Output Adjustment 95%~108% rated output voltage adjustable by internal potentiometer Dimensions 145 x 47 x 30 EMC Standards EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~295VAC Safety Standards UL8750, UL1310, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single Working Temperature -20~+70°C PDF Datasheet PLN-30-SPEC.PDF
