The Meanwell PWM-90-24 is a 90W, 24V constant-voltage LED driver with PWM-style output for LED strip lighting.
- Output: 24V, 3.75A, 90W.
- 3-in-1 dimming: 0-10V DC, 10V PWM signal or resistance.
- Input: 90-305V AC.
- IP67 fully encapsulated housing, Class II design.
- Dimensions: 171 x 63 x 37.5mm.
This is the standard PWM-90-24 model, not the DA2 DALI version. It is not a mains phase-cut/triac dimmable driver. Use a compatible control connected to the dimming leads.
