Wattage:
Voltage:
EAN:
Manufacturer:
Constant voltage PWM form output
0~10Vdc or PWM input signal dimming function
Protections: Short circuit/ Overload/ Over voltage/ Over temperature
Other features:
Universal AC input/ Full range (up to 305VAC)
Dimming range: 0~100%
High efficiency up to 90.5%
Class II power unit, no FG
Suitable for dry/ damp/ wet locations
No load power consumption <0.5W
5 years warranty
More Information Output Wattage (W) 90 Output Voltage Choose Option Dimensions 171x 63x 37.5 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (?60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge L-N: 2KV), criteria A Input Voltage 90~305VAC 127~431VDC Safety Standards UL8750, CSA C22.2 No. 250.13-12, EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved; Design refer to EN60335-1 Output Voltage Options Single Working Temperature -25°C~+70°C PDF Datasheet PWM-90-spec.pdf
More Information Output Wattage (W) 90 Output Voltage Choose Option Dimensions 171x 63x 37.5 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (?60% load) ; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024, light industry level (surge L-N: 2KV), criteria A Input Voltage 90~305VAC 127~431VDC Safety Standards UL8750, CSA C22.2 No. 250.13-12, EN61347-1, EN61347-2-13, EN62384 independent, IP67 approved; Design refer to EN60335-1 Output Voltage Options Single Working Temperature -25°C~+70°C PDF Datasheet PWM-90-spec.pdf
