Wattage:
Voltage:
EAN:
Manufacturer:
- Suitable for use in retail shops, public buildings, communal areas, sports centres, stairwells, corridors, walkways
- LED replacement for 28W 2D fluorescent fittings
- High impact resistant polycarbonate housing
- Impact Rating of IK09
- High efficiency Pro-diffuser allows maximum light transmission, provides low glare, creates even light distribution
- High efficacy of 82lm/W
- Chrome trim available (R282TRIM-03)
- Wide operating ambient temperature range of -20°C to +35°C
- Suitable for switching by PIR, Microwave or Photocell
- Suitable for 24/7 use
IP65330mmWhite4000K
| Total Power (W) | 10.6 |
| Lumens (lm) | 860 |
| Beam Angle | 110 |
| Comparable To | 28W 2D fitting |
| CRI | 80 |
| CCT (K) | 4000 |
| Efficacy (lm/cctW) | 82 |
| Lux at 1m | 270 |
| Power Factor | 0.9 |
| Colour | |
| Cut Out (mm) | |
| Length | - |
| Width | - |
| Height/ Depth (mm) | 118 |
| Diameter (mm) | 330 |
| Unit Weight / kg | 1.40 |
R100LED-01 - Energy Label.pdf
R100LED-03 - Energy Label.pdf
Certificate 004-0005.pdf
GOLF-EU-RXXXLED-ROBUS Product Information Document-09062021 FR.pdf
GOLF-EU-RXXXLED-ROBUS Product Information Document-20210609.pdf
Instruction Manual for R075LED-01, R100LED-01, R100LEDWW-01, R150LED-01 ISSUE 2.pdf
R100LED - Golf Revit 15 Files.zip
R100LED-01-Photometrics.ldt
R100LED-01-Photometrics.IES
